Mô tả ngắn:
NeoDen4--- Máy gắp đặt với hệ thống camera (không điều chỉnh tự động)
Sản phẩm
NeoDen4 là dòng máy mới rất được mong chờ của Neoden, đây là hệ thống máy gắp đặt tự động cùng hệ thống quét ảnh tự động.
Là một nhà thiết kế và phát triển máy PnP chuyên nghiệp, Neoden them gia ngành công nghiệp SMT từ năm 2010. Neoden 4 bao gồm hệ thống camera kép, rails tự động, feeders điện tự động và 4 đầu hút, hỗ trợ tới linh kiện 0201, BGA, QFN, và có khả năng đáp ứng cho LED 0.8m/1.2m/1.5m LED. NeoDen4 là sư lựa chọn hàng đầu bởi độ chính xác cao, tốc độ, sự ổn...
Mô tả ngắn:
Hệ thống X-quang TruView ™ Prime
Hệ thống Xray để bàn mạnh mẽ.
TruView ™ Prime là bằng chứng cho thấy sức mạnh có nhiều kích cỡ. Cho đến nay là thiết bị X-quang để bàn mạnh mẽ và linh hoạt nhất trên thị trường hiện nay, TruView ™ Prime được thiết kế để dễ sử dụng.
Có sẵn trong 3 cấu hình tiêu chuẩn, TruView ™ Prime A là nền tảng cơ bản của chúng tôi có khả năng cho chất lượng hình ảnh đáng kinh ngạc với các yêu cầu đào tạo tối thiểu. TruView ™ Prime A cũng giống như "plug-and-play". TruView ™ Prime R2R là cấu hình reel-to-reel của chúng tôi được thiết kế để tìm kiếm các thành phần giả mạo. Nó nhanh chóng và chính xác. TruView ™ Prime S cung cấp cho bạn một trường nhìn rộng lớn trong...
Mô tả ngắn:
Kích thước nhỏ. Sức mạnh to lớn.
Hệ thống kiểm tra tia X TruView ™ Cube - có kích thước 16 ″ x16 ″ x30 ″ - lý tưởng cho các ứng dụng có không gian làm việc bị hạn chế. Dễ dàng sử dụng và cài đặt, đây là hệ thống linh hoạt và di động nhất trên thị trường hiện nay.
Vì chúng tôi tự phát triển tất cả phần cứng và phần mềm của mình, nên TruView ™ Cube đã được tùy chỉnh cho nhiều ứng dụng. Ví dụ: chúng tôi đã cài đặt một băng chuyền trên đó để chạy mẫu qua máy, chúng tôi đã thêm một robot để di chuyển mẫu vào và ra khỏi máy và chúng tôi đã thêm trí tuệ nhân tạo để tự động xác định xem mẫu có tốt không hoặc tệ. Chúng...
Mô tả ngắn:
Thông số kỹ thuật máy gắp đặt linh kiện NeoDen 3V
Thông tin chung
NeoDen3V là phiên bản nâng cấp của dòng máy TM245P series.
Máy có 2 đầu hút, 46 khe feeder, hệ thống vision, hệ thống đặt PCB linh hoạt, là dòng máy phù hợp cho chế thử, sản xuất vừa và nhỏ với chi phí đầu tư và sản xuất rất hợp lý.
Đặc điểm
2 đầu hút, hệ thống vision
2 đầu hút linh kiện chính xác,...
Mô tả ngắn:
NeoDen4--- Máy gắp đặt với hệ thống camera (rail điều chỉnh tự động)
Sản phẩm
NeoDen4 là dòng máy mới rất được mong chờ của Neoden, đây là hệ thống máy gắp đặt tự động cùng hệ thống quét ảnh tự động.
Là một nhà thiết kế và phát triển máy PnP chuyên nghiệp, Neoden them gia ngành công nghiệp SMT từ năm 2010. Neoden 4 bao gồm hệ thống camera kép, rails tự động, feeders điện tự động và 4 đầu hút, hỗ trợ tới linh kiện 0201, BGA, QFN, và có khả năng đáp ứng cho LED 0.8m/1.2m/1.5m LED. NeoDen4 là sư lựa chọn hàng đầu bởi độ chính xác cao, tốc độ, sự ổn...
Mô tả ngắn:
Product Details
Feature:
1.Using precision guide rail and the import motor to drive the blade seat conversion, printing, and high accuracy.
2.Printing scraper can rotate 45 degrees fixed up, easy printing stencil and squeegee cleaning and replacement.
3.Block can be adjusted before and after the blade, to choose the right printing position.
4.Combined with a fixed groove printing platen and PIN, easy installation and adjustment, for single, double sided printing.
5.School Edition way to move a steel mesh, combined with printed (PCB), X, Y, Z. Convenient fine adjustment.
6.Can be set to one-way and two-way, a variety of printing methods.
7.With the automatic counting function to facilitate the production of output statistics.
8.Adjustable blade angle, steel blade, rubber scraper...
Mô tả ngắn:
Product introduction
Stencil printer PM3040
FEATURES
1) The same platform as printer can be selectable,easy to locate both single and double sides of PCB board,high flexibility ensure high printing precision;
2) The steel stencil can be rotated 30 degrees at most,and the precision can be kept all the way when repeat works,can be comparable with automatic machine;
3) Using the way of steel stencil movement to adjust the best position,combining with the fine adjustment of X-axis、Y-axis to correct,convenient and efficient;
4) The frame made of thickened sheetmetal,finest material,good quality with outstanding durability;the brackets using the bolt bar to adjust the height,convenient for controlling the thickness of PCB
Technical parameters
...
Mô tả ngắn:
Semi-automatic stencil-printer printALL210XL
The semi-automatic stenil printer printALL210XL is the largest of the range. It was espcially constructed for the handling of oversized PCBs. FRITSCH argues about a maximum PCB size up to 1240 x 600 mm. Conditioned by the size the integration of a vacuum table is possible and a safe and smooth intake of PCBs and foils is guaranted.
Learn more:
Details
Quick Setup
The flexible PCB intake enables the stencil printer to be set up within only a few minutes. The adaptions to a different frame format can be made without tools. The optional test print frame reduces the minmial set up time once again.
Quick change frame
Common, sturdy aluminium frames and other usual quick change...
Mô tả ngắn:
Semi-automatic stencil printer printALL210L
The semi-automatic stencil Printer printALL210L is the continuation of the printALL210. Both systems are identic in solid construction and easy operation. This is the base of a clean and reproducable stencil printing and makes the handling of fine structurs possible without any problems. The intake of PCBs with a size of up to 600 x 430 mm are possible at the printALL210L .
Learn more:
Details
Quick Setup
The flexible PCB intake enables the stencil printer to be set up within only a few minutes. The adaptions to a different frame format can be made without tools. The optional test print frame reduces the...
Mô tả ngắn:
The FRITSCH semi-automatic stencil printer is solid built and very easy in operating. These are basics for clean and reproducable printing and finest structures are no problem.
Semi-automatic stencil printer printALL210
The semi-automatic stencil printer printALL210 is solid constructed and the operating is simple. Set-up times are reduced to a minimum because tools aren't necessary. PCBs with max. size of 440 x 430 mm can be realized.
Learn more:
SD903 Video
Details
Quick Setup
The flexible PCB intake enables the stencil printer to be set up within only a few minutes. The adaptions to a different frame format can be made without tools. The optional test print frame...
Mô tả ngắn:
SD360-U Stencilprinter max. stencil size 380 x 270mm.
Technical information
• Dimensions: 510 x 610 x 140 mm(L x W x H)
• Max. PCB: 260 x 360mm
• Max. Stencil:275 x 375mm
• Weight: 17Kg
Description
• Manual operated stencil printer
• Stencils do not need mounting holes.
• Fixing a stencil is fast and easy, no heating of the stencil is required.
• Positioning of PCB’s is simple with the use of magnetic placeholders.
• The stencil printer can be used for single as well as double sided PCB’s. Even if there are already components on one side.
• Accurate X, Y and Rotation alignment of the PCB table.
Mô tả ngắn:
SD300 Stencilprinter max. stencil size 340 x 230 mm.
Technical information
• Dimensions: 520 x 280 x 95 mm(L x W x H)
• Max. PCB: 220 x 320mm
• Max. Stencil:230 x 340mm
• Weight: 9Kg
Description
• Manual operated stencil printer
• Stencils do not need mounting holes.
• Fixing a stencil is fast and easy, no heating of the stencil is required.
• Positioning of PCB’s is simple with the use of magnetic placeholders.
• The stencil printer can be used for single as well as double sided PCB’s. Even if there are already components on one side.
• Accurate X, Y and Rotation alignment of the PCB table.
Mô tả ngắn:
SD240 Stencilprinter max. stencil size 270 x 190mm
Technical information
• Dimensions: 240 x 370 x 110 mm(L x W x H)
• Max. PCB: 180 x 240mm
• Max. Stencil:185 x 275mm
• Weight: 7Kg
Description
• Manual operated stencil printer
• Stencils do not need mounting holes.
• Fixing a stencil is fast and easy, no heating of the stencil is required.
• Positioning of PCB’s is simple with the use of magnetic placeholders.
• The stencil printer can be used for single as well as double sided PCB’s. Even if there are already components on one side.
• Accurate X, Y and Rotation alignment of the PCB table.
